DESCRIPTION

Basic Info.

Model NO.	YH-NPF
Trademark	YH
Origin	China
HS Code	8543300090
Production Capacity	100000pieces/Every Year

Product Description

YH-NPF series lead silver alloy auxiliary anode

Introduction:The electro-depositing Pb-0.8%Ag alloy anode was prepared by lead silver anode electro-depositing lead and silver on the surface of aluminum sheet, and the traditional casting Pb-0.8%Ag alloy anode was prepared by the method of the solid film casting.The electrochemical properties, structure and morphology of two kinds of anodes were studied by constant current polarization, cyclic voltammetry, ac impedance, X-ray diffraction and scanning electron microscopy.The results show that the surface formation of PbO2 is more, the corrosion resistance and the conductivity are better, the surface topography is more compact and even.Features:1. Compared with the casting Pb-0.8%Ag alloy electrode, the anode film of the electro-depositing Pb-0.8%Ag alloy anode is more uniform and compact and more stable.2. The surface formation of PbO2 is more, the corrosion resistance and the conductivity are better, the surface topography is more compact and even.Chemical property:

Material		Use environment	Max. Working current density(A/m2)	consumption(Kg/A.a)	Polarization potential ≤V
Lead silver alloy anode	Contain 20%Ag	In the seawater	50~250	1×10-1	2.0
	Contain 20%Ag		50~300
Lead silver micro-platinum anode		In the seawater	50~1000	8×10-3	2.2

Chemical component:

Chemical elements	Ag	Pb	Impurity ≤
			Fe	Cu
Content	2~3	Remain	0.005	0.03

Application range:Can be widely used in seawater anti-corrosion.

Specification:

Name	Type	Shape	Dimension (mm)				Anode body working area(mm2)	Anode body thickness(mm)	Service life	Work current range
			L(D)	B	H	Installation hole
Lead silver alloy anode	YH-NPF	linear	920	180	40	8	600×50	32	>6	1.5~7.5
	YH-NPF	linear	φ1340	180	40	10	1018×50	32		2.5~12.5
	YH-NPF	disc	φ198	φ146	25	-	16700	35		0.8~5.0
	YH-NPF	disc	φ290	φ245	30	-	50000	40		2.5~15
